BRITISH MADE!

Designed for welding or screwing into a stainless steel worktop or tabling, through an aperture of 277 x 277mm. Other sizes available to special order & quotation. Supplied complete with wall mounted motor control box incorporating 12 volt printed circuit.
Unit incorporates lockable hopper lid which is fully electrically interlocked to prevent hand access to the grinding head whilst the machine is running. Hopper & lid manufactured entirely from stainless steel.

Fitted motor - ½hp high torque continuously rated reversing motor which is fan cooled with capacitor start & incorporating thermal cut-out. The units have precision cutting head & the rubber housing is particularly efficient at absorbing vibration & reducing noise levels. All types supplied complete with ‘S’ trap for connection to 2” waste pipe. The outlet is fully adjustable through 360° to suit any particular installation.

Operation is fully automatic. Immediately the unit is switched on the solenoid valve fitted to the water supply is actuated. The flow rate consumption is approximately 12 to 16 litre/minute.

Electrical control equipment - it reduces the input voltage 240v to 12v & ensures greater safety in the possible event of an electrical fault. A PRINTED CIRCUIT incorporates a no-volt release device.

ELECTRICAL: Connection to be made from a fused isolator. All units supplied with 2 metres mains cable wired into the control box.

WATER SUPPLY: 15mm cold water supply should be connected to the ½”BSP connection on the solenoid valve which provides automatic water flow each time the machine is started. Minimum water head 5 metres. For best results flow rate should be approximately 12 - 16 litre per minute.

WASTE CONNECTION: 54mm plastic or copper pipe to be connected to ‘S’ trap supplied with units, laid to a minimum fall of 1 in 16. The pipework should be as simple as possible with no sharp bends.

MAINTENANCE: No routine maintenance is required other than regular cleaning & inspection. A release key is provided to free the rotor should it become jammed.

1 YEAR PARTS & LABOUR WARRANTY.

Lease to buy from £11.04 per week!

Price: £1227.00

Waste Capacity: 150 kg/hr.
Meals per day: 500.
Motor Power: ¾ hp.

Water Connection: 15mm.
Waste Connection: 1½" BSP (Male).
Water Consumption: 13 ltr/min.
Comes with one touch reverse.
1 Phase: 220/240v, 13 amps.
3 Phase: 380/420v, 5 amps.
Optional cutlery saver prevent any loss of ferrous items - POA.

Price: £1332.80

Waste Capacity: 175 kg/hr.
Meals per day: 750.
Motor Power: 1½ hp.

Water Connection: 15mm.
Waste Connection: 1½" BSP (Male).
Water Consumption: 13 ltr/min.
Comes with one touch reverse.
1 Phase: 220/240v, 13 amps.
3 Phase: 380/420v, 5 amps.

Optional cutlery saver prevent any loss of ferrous items - POA.

Price: £1344.20

Waste Capacity: 425 kg/hr.
Meals per day: 1000.
Motor Power: 3 hp.

Water Connection: 15mm.
Waste Connection: 2" BSP (Female).
Water Consumption: 13 ltr/min.
1 Phase: 220/240v, 13 amps.
3 Phase:380/420v, 5 amps.
Optional cutlery saver prevent any loss of ferrous items - POA.

Price: £1607.80

Waste Capacity: 850 kg/hr.
Meals per day: 2000.
Motor Power: 5 hp.

Water Connection: 15mm.
Waste Connection: 2" BSP (Female).
Water Consumption: 13 ltr/min.
3 Phase: 380/420v, 5 amps.

Optional cutlery saver prevent any loss of ferrous items - POA.

Price: £1683.10
