Electrolux 232189 Electric 100 Litre Tilting Indirect Heat Boiling Pan

Electrolux's range of high productivity boiling pans are designed to uniformly heat food in the base ans side walls of the kettle by an indirect heating system that uses an indirect heating system. Electrolux tilting kettle uses integrally generated saturated steam at a temperature of 108°C in the jacket with an automatic deceleration system.

Product Features:

• High thermal input and fast heat up.
• Ergonomic vessel dimensions, with a large diameter and shallow depth facilitates stirring and gentle food handling.
• Curved pan base guarantees that the appliance is also suitable to prepare small quantities of food.
• Safety thermostat protect against low water level.
• Safety valve avoids overpressure of the steam in the jacket.
• High quality thermal insulation of the pan saves energy and keeps operating ambient temperature low.
• Compliant to CE requirements for safety.
• Constructed to meet the highest hygiene standards.
• Safe thanks to the higher water protection IPX5 and the lower temperature outside panels.
• Fast working thanks to the high efficient heating technology and well insulation that keeps heat inside the well.
• AISI 304 stainless steel construction, including deep drawn pan with rounded edges.
• Max pressure at 0.5 bar.
• Vessel can be tilted beyond 90° to completely empty the food.
• motorised tilting.
• Electromechanical control.
• Ergonomic and user friendly thanks to the high tilting position and the pouring lip design which allow to easily fill containers.
• Tilting axis located in the middle of the pan keeps the pouring lip high and allow tall vessels to be filled.
• Electric heating elements are submerged directly in the water of the jacket, the heat losses are vert low and the efficiency of the pan accordingly high.

Working temperature minimum: 30°C.
Working temperature maximum: 108°C.

Net vessel useful capacity: 100 litre.

Automatic tilting mechanism.

Central bearing.

Please note:

To install this unit you need the following parts.
• 928000 - Left leg/ column (this does not come with the machine as you can sweet up more than one unit and therefore would not need this leg for each unit).
• 928002 - Fixture - 1 needed per pan.
• 2 x 928003 - Installation frame (to bolt the unit the unit to the floor).

Optional extra:
• 928012 - Strainer with 8mm holes.

2 year Parts & Labour warranty.

New

Dimensions:
W 1068 X D 780 x H900mm
Weight: 106Kg

Power Requirements:
15kW
400V, 50Hz, 32AMP, Three Phase, Requires hard wiring.

Special Requirements:
3 phase
Please refer to manufacturers specification
